ABB CI855K01 3BSE018106R1 dedicated communication interface module

Sales manager: Vicky.gan Email: vicky@kerienplc.com Mob(Whatsapp/Wechat) :+ 86 13695017671 QQ：259680581 Skype :+ 86 13695017671

CI855K01 3BSE018106R1 is a dedicated communication interface module launched by ABB, mainly used in the field of industrial automation. It supports multiple communication protocols and has high reliability and scalability

Core functions

Multi protocol support

Supports industrial communication protocols such as Modbus (RTU/ASCII), Profibus DP, Profinet, EtherCAT, etc., with strong compatibility and the ability to connect devices from different manufacturers.

Specially designed for the DriveBus protocol, it enables high-speed and reliable communication between ABB frequency converters and AC800M controllers, supporting state monitoring, parameter adjustment, and fault diagnosis.

System integration capability

As a communication bridge of MasterBus 300 (MB300) protocol, it can connect old and new control systems (such as System 800xA new system and Advant Controller 410/450 old system) to achieve point-to-point data exchange.

Support physical star topology, build logical bus through branch unit NDBU, simplify wiring and improve system scalability.

Network redundancy and hot plugging

Equipped with dual RJ45 Ethernet ports, supporting network redundancy to ensure communication continuity.

Support hot swapping, easy to maintain and expand, and can replace modules without shutting down.

Technical specifications

Physical characteristics:

Size: Approximately 185mm × 59mm × 127.5mm

Weight: Approximately 0.7kg

Protection level: IP20 (to be installed inside the control cabinet)

Installation method: DIN rail installation

Electrical performance:

Working voltage: 24V DC

Typical power consumption: 150mA

Working temperature range: -20 ° C to+60 ° C (up to 55 ° C in some scenarios)

Communication performance:

MB300 transmission speed: 10 Mbit/s, supporting the transmission of 200 datasets per second

Modbus RTU baud rate: 9600bps to 115200bps

Up to 12 units can be connected on the CEX bus

One CI855 can connect up to 24 ABB frequency converters

Application scenarios

Industrial automation system

Connect PLC, HMI, sensors and other devices to achieve data acquisition and control, and support the coordinated operation of complex production processes.

Process control system

In the fields of chemical engineering, petrochemicals, pharmaceuticals, etc., reliable communication between equipment is achieved to support monitoring and optimization of production processes.

Power system integration

Integrate power equipment and systems, achieve centralized control and monitoring, and improve the efficiency of power grid operation.

Building automation

Connect devices such as air conditioning, lighting, and safety systems to achieve intelligent control and energy management.

Remote monitoring and control

Suitable for distributed systems such as remote sites and telemetry stations, supporting real-time data transmission and remote operations.

Rolling mill and paper machine drive system

Implementing segmented drive control through the DriveBus protocol to meet industrial demands for high precision and reliability.

Summary of Advantages

Strong compatibility: Supports multiple communication protocols and can connect devices from different manufacturers.

High reliability: Adopting redundant design and high-quality materials to adapt to harsh industrial environments.

High scalability: Supports multiple frequency converter connections and physical star topology, simplifying system expansion.

Easy to maintain: Hot swappable function and LED status indicator light reduce maintenance costs.

Flexible application: Suitable for multiple fields such as industrial automation, process control, and building management.
