ABB CI853K01 3BSE018103R1 communication interface module

Sales manager: Vicky.gan Email: vicky@kerienplc.com Mob(Whatsapp/Wechat) :+ 86 13695017671 QQ：259680581 Skype :+ 86 13695017671

CI853K01 3BSE018103R1 is a dual RS232-C communication interface module from the AC 800M series under ABB:

1. Product positioning and functions

Type: This module belongs to the communication component of the ABB AC 800M controller series, specifically designed for data exchange in industrial automation systems.

Function: Supports serial communication with third-party devices or traditional systems, enabling data interconnection between different devices.

II. Technical Parameters

Interface type: Includes 1×RS-232 (full duplex, point-to-point communication) and 1×RS-422/RS-485 (half duplex/full duplex, supports multi-point communication).

Baud rate: Supports configurable baud rates ranging from 300 bps to 115.2 kbps.

Protocol support: Includes Modbus RTU (master/slave), generic ASCII protocol (custom protocol), and COMLI protocol (data transmission protocol between ABB controllers).

Optoelectronic isolation: The RS-422/RS-485 port features 500V electrical isolation, effectively preventing ground loop interference.

Environmental adaptability: Operating temperature range is -25°C to +70°C (industrial-grade wide temperature range), protection level is IP20 (must be installed inside a control cabinet), humidity range is 5% to 95% without condensation.

Power supply method: Powered through the AC 800M backplane (24V DC), with a power consumption of approximately 2-5W (low-power design).

III. Product Features and Applications

Multi-protocol support: This module supports multiple industrial communication protocols, including but not limited to PROFIBUS DP, Modbus, EtherNet/IP, etc., ensuring seamless integration with various automation devices.

High-performance processing: Equipped with a high-performance processor, it can swiftly manage extensive data exchanges, catering to application scenarios demanding high real-time performance.

Flexible configuration: Users can flexibly configure modules through software tools, including setting parameters such as baud rate, data bits, stop bits, etc., to adapt to the communication needs of different devices.

Redundancy design: Supports redundant configuration to enhance system reliability and availability, ensuring smooth communication even in the event of a single failure.

Easy to integrate: The compact design facilitates installation and provides standardized interfaces, simplifying the system integration process.

Application areas: In industries such as petrochemicals, electric power, machinery manufacturing, and food processing, the CI853K01 module can provide a solid communication foundation for automated control systems.
