ACS800-104-0510-3 Frequency Converter Model Analysis and Technical Characteristics

ACS800-104-0510-3+C126+E205+Q967+V991 is a high-performance frequency converter configuration model launched by ABB, widely used in industrial automation transmission systems

Model composition and core parameters

Basic model meaning:

ACS800: ABB Classic Inverter Series, supports multiple control modes and power ranges.

104: Indicates that the module type is a bookshelf inverter module, suitable for multi drive system cabinet integration.

0510-3: Power related parameters, estimated corresponding to rated output current or power level (refer to ABB official manual for details).

Function of suffix options:

C126: Control card component, providing digital signal processing and system communication interface.

E205: EMC filter, used to suppress electromagnetic interference and meet the electromagnetic compatibility requirements of industrial environments.

Q967/V991: It may be a specific functional module (such as power monitoring, voltage regulation, or extended I/O), which needs to be confirmed in conjunction with the ABB option code table.

Technical characteristics and application scenarios

Hardware architecture: Adopting AC-DC-AC topology structure and PWM pulse width modulation technology, the inverter bridge integrates IGBT devices, with high-frequency chopping capability and optimized low-frequency operating characteristics.

Control performance: Supports vector control mode, high control accuracy, flexible parameter configuration, suitable for complex industrial loads (such as motor speed regulation, pump/fan drive).

Typical application: Suitable for high-power transmission systems in metallurgy, chemical industry, power and other fields, it can expand power through multi module parallel connection or be linked with PLC, industrial robots and other equipment.
