5SHY35L4512 3BHE014105R0001 is an Integrated Gate Commutated Thyristor (IGCT) module produced by ABB

product positioning

Brand and Type: 5SHY35L4512 3BHE014105R0001 is an IGCT module from the ABB brand, specifically designed for medium and high-voltage frequency converters and large-scale power electronics assemblies.

Technical Characteristics

Rated voltage and current: The rated voltage is 3500V and the rated current is 4500A, meeting the application requirements of high voltage and large current.

High reliability: By combining the stable turn-off capability of transistors and the low on-state loss of thyristors, the reliability is improved.

Fast switching capability: With high-speed switching capability, no snubber circuit is required, fewer power components are needed, and the reliability of operation is greatly enhanced.

Optimization design: Optimized for low conduction loss, the improved loss characteristics allow high-frequency applications to be extended to the kHz range.

Hardware fault self-detection function: It can promptly send out alarm information in case of a fault.

Peripheral device fault self-diagnosis function: Users can write fault self-diagnosis programs for peripheral devices in application software, enabling circuits and devices other than the IGCT module in the system to receive fault self-diagnosis protection.

Application scenarios

Medium and high voltage frequency converters: They play a pivotal role in medium and high voltage frequency converters, facilitating the conversion and control of electrical energy.

Industrial automation system: In the industrial automation system, we provide stable and reliable power control solutions for various automation equipment.

Power system: It can be used for high-voltage direct current transmission, flexible alternating current transmission systems (FACTS), etc., to achieve long-distance transmission and flexible control of large-capacity power, and improve the stability and transmission efficiency of the power system.

Industrial Drive: In the field of large industrial motor drives, such as speed control systems for high-power motors used in steel rolling mills, mine hoists, and cement mixers, we can provide efficient and reliable power conversion and control, enabling energy-saving operation and precise control of the motors.

New energy power generation: In the fields of new energy such as wind power generation and solar power generation, it is used in inverters to convert the direct current (DC) generated by new energy power generation into alternating current (AC), which is then fed into the power grid or supplied to local loads, thereby improving the efficiency and stability of new energy power generation.

Rail transit: In the traction systems of high-speed trains and urban rail transit, it serves as a power conversion device, providing appropriate power to the traction motors of the trains, enabling speed regulation and operation control of the trains.

Metallurgical and petrochemical industries: In the drive systems of equipment such as electric arc furnaces and refining furnaces in the metallurgical industry, as well as various high-power pumps and compressors in the petrochemical industry, they play a role in power conversion and control, ensuring stable operation and efficient production of the equipment.
