ABB 3BSE042235R2 PP845A touch screen

Sales manager: Vicky.xia Email: vicky@kerienplc.com Mob(Whatsapp/Wechat) :+ 86 13695017671 QQ：259680581 Skype :+ 86 13695017671

3BSE042235R2 PP845A is a high-performance industrial touch screen control panel launched by ABB, belonging to the Panel 800 series, mainly used in the field of industrial automation

1、 Core Features

Display Technology

Adopting TFT/LED display technology, equipped with a 10.4-inch color touch screen with a resolution of 800 × 600 pixels.

The display screen is clear, with vivid colors, supporting graphic and text display, providing operators with an intuitive visual experience.

Communication Protocol

Supports multiple protocols such as PROFIBUS DP, seamlessly integrates with PLCs and other automation devices, ensuring real-time and accurate communication and data transmission.

Some models (such as 3BSE042235R2) support bus redundancy function, which can achieve mutual conversion between single bus and redundant dual bus, improving system reliability and availability.

Human Machine Interface (HMI)

Equipped with a friendly HMI and intuitive operation mode, users can easily get started without the need for long training.

Provide comprehensive templates and libraries to facilitate users in customizing user interfaces according to their needs and quickly building interfaces that meet practical application scenarios.

Hardware configuration

Equipped with high-performance ARM processors and large capacity memory, ensuring fast response and stable operation.

The sturdy and lightweight cast aluminum alloy shell design is suitable for harsh industrial environments and has good protective performance (protection level IP30 or higher).

The working temperature range is -10 ° C to+60 ° C, suitable for various industrial scenarios.

2、 Functional advantages

Equipment control

By using a touch screen to start, stop, and adjust parameters of the device, the flexibility and controllability of the production process can be improved.

Data monitoring

Real time display of equipment operating status, production data, and other information, helping operators to timely grasp the production situation and make accurate decisions.

Alarm management

When equipment malfunctions or production data exceeds the set range, timely alarm signals are issued to remind operators to handle and ensure production safety.

Alarm and event messages are stored in a list arranged in chronological order, supporting loop coverage and confirmation mechanisms to ensure that critical information is not overlooked.

Redundant design

Some models support bus redundancy function, such as the 3BSE042235R2 module, which can achieve mutual conversion between single bus and redundant dual bus, improve system reliability and availability, and is suitable for occasions with high requirements for system stability.

3、 Application scenarios

Manufacturing industry

Used for production line monitoring, equipment control, etc., to improve production efficiency and product quality.

Energy industry

In the fields of electricity, oil, natural gas, etc., remote monitoring and operation of equipment are achieved to ensure the safety and stability of energy supply.

Logistics industry

Used for warehouse management, cargo sorting, and other processes to improve the efficiency and accuracy of logistics operations.

Food and beverage industry

Realize precise control and monitoring during the production process to ensure that the product meets hygiene and quality standards.

4、 Model difference

PP845A: Standard configuration, 10.4-inch TFT touch screen, suitable for most industrial automation scenarios.

PP845A 3BSE042235R2: A fieldbus redundant link module that supports the PROFIBUS DP protocol, with stronger communication capabilities and redundant design, suitable for applications that require high system reliability.
